The 10-32 Female Elbow Connector is a convenient fitting designed for microfluidic systems requiring an L-type flow path. It ensures a leakage-free connection for rigid tubing systems while offering excellent biocompatibility and chemical resistance. Sold individually.
General
This 10-32 Female Elbow Connector is a high-performance solution designed to create a secure 90-degree turn in your fluidic system. Manufactured from PEEK (Polyetheretherketone), this component is the premium choice for applications demanding the highest levels of chemical resistance, pressure tolerance, biocompatibility, and mechanical integrity.
While our polypropylene (PP) connectors are a cost-effective and reliable choice for many general-purpose, low-pressure applications, our PEEK connectors are designed for more demanding scenarios.
Features
- Elbow Design: The 90-degree angle is so convenient for routing tubing around corners or in tight spaces, optimizing system layout and preventing tubing from kinking.
- Mounting Holes: The two mounting holes allow the connector to be securely fastened to a manifold or panel. This adds stability to the system, reduces stress on the tubing and connections, and prevents the connector from moving or rotating during use.
- Biocompatibility: PEEK is biologically inert and non-toxic, which is critical for biomedical and life science applications where the fluid comes into contact with biological samples, cells, or tissues.
- Chemical Compatibility: PEEK is highly resistant to a vast range of aggressive solvents, acids, and bases. This means the connector won't degrade over time and, critically, it won't leach contaminants into your samples.
Content
1x 10-32 Female Elbow connector
Specifications
| SKU |
DM-AD-047 |
| Wetted Material |
PEEK |
| Material |
PEEK |
| Port Type |
10-32 (F, coned) |
DM-AD-047
Documentation
Check the chemical compatibilities for this product here: PEEK - Chemical Compatibility Chart
