Whereas standard ChipShop connectors only accept soft-walled tubing, this set of connectors allows connecting
any 1/16" OD rigid tubing to a ChipShop chip.
Suitable for rigid tubing (PTFE, PEEK, etc.) with an OD of 1/16" (1.6 mm). Manufactured in blue TPE, max.
pressure of 3.2 bar with a 1/16" OD PEEK tubing.
Plugs to block unused ports are also available in our shop.
See All Availability
Use the filter to narrow your search
EasyPump pump head with 4 rollers for Innofluid peristaltic pumps.
Available with adjustable or fixed tubing occlusion and 1 or 2 channels, with free silicone tubing included.
General
The EasyPump peristaltic pump head is designed for versatile flow rates, ranging from 5.3 µL/min up to 3100 mL/min, depending on the tubing size and driver used. It can be mounted on different drivers, including the Lab series pump drivers, with up to 600 rpm motor speed. Compatible with standard tubing without stoppers, this pump head has 4 rollers and 1 or 2 simultaneous channels. According to your needs, the tubing occlusion can be fixed or adjustable, extending tube life and improving dispensing accuracy.
Pump head options
Pump head
Occlusion
Number of channels
Tubing wall thickness
EasyPump I
Fixed
Single (1)
1.6 mm
EasyPump II
Fixed
Single (1)
2.4 mm
EasyPump V
Fixed
Dual (2)
1.6 mm
EasyPump III
Adjustable
Single (1)
1.6 mm
EasyPump IV
Adjustable
Single (1)
2.4 mm
EasyPump VI
Adjustable
Dual (2)
1.6 mm
Tubing & Flow range
Pump Head
Tubing
Tubing ID x WT (mm)
Flow rate (mL/min) (0.1 - 150 rpm)
Flow rate (mL/min) (0.1 - 350 rpm)
EasyPump I
EasyPump III
(Single Channel)
13#
0.8 x 1.6
0.0053 - 8
0.0053 - 19
14#
1.6 x 1.6
0.027 - 41
0.027 - 95
19#
2.4 x 1.6
0.055 - 83
0.055 - 193
16#
3.1 x 1.6
0.0933 - 140
0.093 - 327
25#
4.8 x 1.6
0.1967 - 295
0.197 - 688
17#
6.4 x 1.6
0.3333 - 500
0.333 - 1167
18#
7.9 x 1.6
0.43 - 645
0.43 - 1505
EasyPump II
EasyPump IV
(Single Channel)
15#
4.8 x 2.4
0.18 - 270
0.18 - 630
24#
6.4 x 2.4
0.2733 - 410
0.273 - 957
35#
7.9 x 2.4
0.3833 - 575
0.383 - 1342
36#
9.6 x 2.4
0.5167 - 775
0.517 - 1808
EasyPump V
EasyPump VI
(Dual Channel)
13#
0.8 x 1.6
0.0053 - 8
0.0053 - 19
14#
1.6 x 1.6
0.027 - 41
0.027 - 95
19#
2.4 x 1.6
0.055 - 83
0.055 - 193
16#
3.1 x 1.6
0.0933 - 140
0.093 - 327
25#
4.8 x 1.6
0.1967 - 295
0.197 - 688
Content
1x EasyPump pump head
With the EasyPump pump I, III, V, and VI, for each channel:
1x 2m of 25# (4.8 x 1.6 mm ID x WT) peristaltic tubing
With the EasyPump pump II and IV, for each channel:
1x 2m of 15# (4.8 x 2.4 mm ID x WT) peristaltic tubing
The DG15-24, DG15-28 and DG15-48 pump heads from Longer are multichannel heads for medium to low flow rates.
Available with 4 or 8 rollers and 2 or 4 channels, free silicone tubing included...
YZ2515X pump head for Longer peristaltic pumps. Based on an automatic tubing retention mechanism, this pump head allows using a wide range of tubing dimensions and formulations without stoppers.
Free...
FG15-13 and FG25-13 pump heads are designed for medium to high flow rate. It is easy to change tubing quickly thanks to the flip cover: open the flip, load your tubing, and close it.
Free silicone...
YZ1515X pump head for Longer peristaltic pumps. Based on an automatic tubing retention mechanism, this pump head allows using a wide range of tubing dimensions and formulations without stoppers.
Free...
AMC pump head for Innofluid peristaltic pumps, designed for low flow rates.
Available with 6 or 10 rollers and 1, 2, 3, 4, 5, 6, 8, 10, and 12 channels, with free silicone tubing included...
