ZEISS Stemi 355, configured for microfluidics devices inspection.
Compact stereo microscope with true 3D viewing, 5.5:1 zoom (7.2x to 40x), and flexible C LED illumination options. Ideal for fast daily observation of microfluidic chips and parts, and for easy documentation with a camera. Camera not included.
General
Your stereo microscope for daily chip checks
Stemi 305 is a compact Greenough stereo microscope with a 5.5:1 zoom range. It lets you observe samples as they are, in real 3D, distortion-free and crisp in contrast, with minimal setup. This configuration is practical for microfluidics, where quick visual checks of chips, channels, connectors, and assemblies matter.
The C EDU stand provides a stable working area. The included LED illuminators help you tune lighting to the surface you want to inspect, from general viewing to highlighting defects.
Typical microfluidics uses
- Inspection of microfluidic chips before experiments (channel cleanliness, debris, damage)
- QC checks during fabrication or assembly (bonds, interfaces, alignment)
- Observation of connectors, tubing interfaces, and chip fittings
- Surface inspection and defect detection using segmentable ring illumination
Key features
Fast to set up, comfortable to use, and easy to document.
True 3D viewing with 5.5:1 zoom
Zoom from 7.2x to 40x to move quickly from an overview of the chip to a detailed inspection of features and interfaces.
Lighting that reveals defects
Use the double spot to shape contrast and the segmentable ringlight to enhance edges and reveal scratches or surface marks.
Stable C EDU stand
A robust bench stand with a comfortable working area and integrated power, designed for daily use and repeatable positioning.
Documentation-ready (trinocular)
The trinocular body makes it easy to add a camera for capturing images and videos for reports, training, or QC documentation.
Content
1x Stemi 355 trinocular body (435066-9010-000)
2x Eyepiece eyecup (444801-0000-000)
1x Stand C EDU (435066-9010-000)
1x Double spot illumination C LED (435528-9010-000)
1x Segmentable ringlight C LED (435528-9020-000)
Country-specific power plug
Quick Start Guide and User Manual
Specifications
Optical system
| Operation concept |
Stereo microscope, Greenough design with 5.5:1 zoom range and five click-stop positions: 0.72x, 1x, 2x, 3x, 4x. |
| Magnification range |
7.2x to 40x with basic version (10x eyepieces). Using interchangeable optics, magnifications from 3.6x to 200x are accessible (not included). |
| Max. resolution |
245 lp/mm – 2.04 μm with basic version, up to 490 lp/mm with interchangeable optics (not included) |
| Working distance |
110 mm basic version, up to 185 mm using interchangeable optics (not included) |
| Maximum object field |
32 mm basic version, up to 64 mm using interchangeable optics (not included) |
| Viewing angle |
45°, interocular distance adjustable 55 to 75 mm |
| Interface to Stemi mount |
76 mm (international) |
| Eyepieces |
PL10x/23 Br. foc |
Stand and illumination
| Bench stand |
Model C EDU with controls for reflected light illuminators C LED and built-in flat transilluminator (brightfield / darkfield) |
| LED illuminators included in this configuration |
Double spot C LED
Segmentable ringlight C LED |
Documentation
Stemi 355 brochure
Quick start guide included in the bundle
Instruction manual included in the bundle
